| Part Number | ESCRDT11-M01C | Cable Length | 0.5m~3m |
| Form Factor | QSFP-56 | Power Consumption | <0.5W |
| Wire AWG | 28~30AWG | Jacket Material | PVC |
| Case Temperature(℃) | 0℃ to +70℃ | Application | 200G Ethernet |
Compatible with IEEE 802.3bj and IEEE 802.3cd
Supports aggregate data rates of 200Gbps(PAM4)
Optimized construction to minimize insertion loss and cross talk
Pull-to-release slide latch design
26AWG through 30AWG cable
Straight and break out assembly configurations available
Customized cable braid termination limits EMI radiation
Customizable EEPROM mapping for cable signature
RoHS omplia
Supports 200Gbps high-speed data transmission for next-generation data centers
Adopts PAM4 modulation technology for higher transmission efficiency
Low power consumption and ultra-low latency reduce operating costs
More cost-effective compared with optical transceiver solutions
Plug-and-play design for easy deployment and maintenance
Excellent EMI performance and signal integrity
Compliant with IEEE 802.3 and InfiniBand HDR standards
Ideal for short-reach high-speed interconnections
Short-reach interconnects in hyperscale data centers
Top-of-Rack (ToR) switch interconnections in data centers
Cloud computing network infrastructure
AI/GPU cluster networking
High-Performance Computing (HPC) systems
High-speed connections between servers and switches
Storage Area Networks (SAN)
ESOPTIC is equipped with a comprehensive range of professional testing equipment designed to assess various parameters of optical products.
This ensures the highest performance, quality, and stability of optical transmission in all of our products.
Put DAC module into electrostatic bag (note module direction) and label.
The bottom, surface and side of the carton are filled with one piece of anti-static foam to protect the product.
According to the packing quantity requirements, put the products packed in anti-static ziplock bags into packaging cartons.
The space left in the trunk must be filled with anti-static foam to ensure that it will not be damaged in transit.
The outer case label is attached to the side position of the outer case.Label the outer case after sealing.
At the time of delivery, the entire outer box should be wrapped with at least 4 layers of wrapping film protection.
※The space in the box and the space in the mantissa box shall be filled with foam.
